Bosch Rexroth A6VM series 71 - Dimensional Data: Size 85 EP5;EP6 Control; Size 85 EP5;EP6 C2 Flange Dimensions

RE-A 91610/12.2015, Bosch Rexroth Corp.
Axial piston variable motor | A6VM series 71
Dimensions size 85
31
Dimensions [inch (mm)]
Dimensions size 85
EP5, EP6 – Proportional electric control, negative control, with Mounting flange C2
Port plate 2 — SAE working ports A and B at side, opposite
T
2
T
1
U
M
1
3.58 (91)
Y
G
5.55 (141)
11.61 (295)
10.35 (263)
1)
6.57 (167)
0.50 (12.7) 0.91 (23)
3.15 (80)
1.08 (27.5)
7.17 (182)
1.34 (34)
1)
0.91 (23)
9.13 (232)
2.25
(57.2)
0.98
(25)
1.09
(27.8)
DIA4.998 DIA5.000
Z
5.67 (144)
0.43 (11)
3.94 (100)
0.69
(17.5)
7.13 (181)
8.39 (213)
12.5°
G
(DIA127
-0.05
)
M
1
View Y
Flange SAEJ744
1) Port plate 1 — SAE working ports A and B at rear
Center of gravity
