Bosch Rexroth A6VM series 71 - Size 85: EP5;EP6 Control with Mounting Flange C4; Size 85 EP5;EP6 C4 Flange Dimensions

Bosch Rexroth Corp., RE-A 91610/12.2015
32 A6VM series 71 | Axial piston variable motor
Dimensions size 85
Dimensions [inch (mm)]
Dimensions size 85
EP5, EP6 – Proportional electric control, negative control, with Mounting flange C4
Port plate 2 — SAE working ports A and B at side, opposite
View Y
M
1
G
Y
M
1
G
Y
T
2
3.58 (91)
5.55 (141)
11.61 (295)
0.50 (12.7) 0.83 (21)
3.15 (80)
9.13 (232)
3.94 (100)
Z
0.56
(14.3)
4.51 (114.5)
6.14 (156)
12.5°
T
U
6.06 (154)
4.51 (114.5)
0.91 (23)
2.25
(57.2)
1.09
(27.8)
DIA4.998 DIA5.000
(DIA127
-0.05
)
0.98
(25)
5.79 (147)
10.35 (263)
1)
1.08 (27.5)
0.33 (8.44)
1.34 (34)
1)
7.17 (182)
6.57 (167)
0.0047
(0.12)
Flange SAEJ744
1) Port plate 1 — SAE working ports A and B at rear
Center of gravity
