5.8 Wear parts
5.8.1 Read-only memory
The physical read-only memory (eMMC) of the control has a limited number of write cycles. Retrieve the
current status of the read-only memory via the ctrlX CORE web interface:
“ctrlX CORE side navigation
🠂
Settings
🠂
Information
🠂
tab "Resources"
🠂
Sensors”
.
Notes on sensor values:
• "0 - 10% of eMMC life time used" means that up to 10 % of the maximum write cycles can be used.
• Create a backup if the value exceeds 80%.
•
Replace the hardware if the value exceeds 80%.
•
Use an external memory to extend the service life of the permanent memory.
• The frequency of the refresh cycle depends on the service life of the memory. If a refresh cycle is
not possible anymore, data can be lost.
5.8.2 Fan
The maximum service life of the fan unit is 50,000 hours. The fan unit then needs to be replaced. For
the ordering data, refer to ⮫ Chapter 5.5 “Fan unit” on page 11.
6 Ambient conditions
6.1
Ambient conditions of the ctrlX CORE
Ambient temperature during operation Up to 2,000 m: -25 °C to +55 °C
2,000 m to 3,000 m: -25 °C to +50 °C
3,000 m to 4,000 m: -25 °C to +45 °C
4,000 m to 5,000 m: -25 °C to +40 °C
Ambient temperature during storage and transport -40 °C to +70 °C
Operating altitude acc. to DIN 60204 Up to 5,000 m above sea level
Permitted air humidity according to
DIN EN 61131-2
5% to 85%, no condensation
Protection class acc. to DIN EN 60 529 IP 20 (not evaluated by UL)
Protection class acc. to DIN EN 61010-2-201 III
Overvoltage category acc. to IEC 60664-1 2
Contamination level acc. to EN 61010-1 2, no condensation allowed
Mechanical tests
Vibration resistance acc. to DIN EN 60068-2-6
①
Oscillations, sinusoidal in all three axes
5 Hz - 8.4 Hz with 3.5 mm amplitude
8.4 Hz -150 Hz with 1 g peak acceleration
Shock test acc. to DIN EN 60068-2-27 Shock stress: Shock resistance in all three axes, 11
ms semi-sinusoidal 15 g
