ctrlX CORE X7
Dismounting the control
Bosch Rexroth AG
R911419122, Edition 01
The control has up to 50 mounting cycles.
10.3.1 Mounting the fan
1. Engaging hook at the rear side of the fan ➁.
2.
Hinge down the fan until the locking hook ➀ is engaged at the front of the control.
1
2
2
Fig. 11: Fan mounting
10.4 Dismounting the control
For dismounting, use a common tool such as a slotted screwdriver with a 2.5 mm blade.
