12.3.3 Motor Name Plate Data
This function is about motor nameplate parameters configuration, most of motor
data are available on the motor nameplate, based on which the following param-
eters of the frequency converter need to be set accordingly.
Code Name Setting range Default Unit Step Attri.
C1.05 Motor rated power 0.1...1,000.0 kW DOM kW 0.1 Stop
C1.06 Motor rated voltage 0...480 V DOM V 1 Stop
C1.07 Motor rated current
0.01...655.00 A
(0.4...37 kW)
DOM A
0.01
Stop
0.1...6550.0 A
(45 kW and above)
0.1
C1.08 Motor rated frequency 5.00...400.00 Hz 50.00 Hz 0.01 Stop
C1.09 Motor rated speed 1...60,000 DOM - 1 Stop
C1.10 Motor rated power factor 0.00...0.99 0.00 - 0.01 Stop
C1.11 Motor poles 2…256 4 - 1 Stop
The input of rating plate data must correspond with the wiring of the motor
(star / delta). This means, if delta wiring is used for the motor, delta rating plate
data has to be entered:
