12.18 H1: PROFIBUS Settings
12.18.1 PROFIBUS Basic Settings
This function is used to set parameter or read parameters when use PROFIBUS
communication extension card.
Code Name Setting range Default Unit Step Attri.
H1.00 PROFIBUS local address 0...126 1 - 1 Stop
H1.01 Present baud rate
0: None
1: 9.6 kbps
2: 19.2 kbps
3: 45.45 kbps
4: 93.75 kbps
5: 187.5 kbps
6: 500 kbps
7: 1,500 kbps
8: 3,000 kbps
9: 6,000 kbps
10: 12,000 kbps
- - - Read
H1.02 Present telegram type
1: PPO1
2: PPO2
3: PPO3
4: PPO4
5: PPO5
6: PPO6
7: PPO7
8: PPO8
- - - Read
●
H1.00 'PROFIBUS local address' is unique station address definition and
needs to be set as equal to master configuration.
● H1.01 'Present baud rate' will display auto-detected baud rate.
● H1.02 'Present telegram type' indicates telegram type selected for communi-
cation network.
● Both H1.01 and H1.02 will be automatically checked after communication be-
tween master and frequency converter established successfully.
