16/54 Function
Bosch Rexroth AG, MIT: LU 2, 3 842 358 814/2017-01
5. Turn on the power to the lubrication unit.
Make the electrical connection to the product see page 38.
The plug icon (cable break detection, see page 25) appears in the display and
the arrow icon
d flashes in the display. The drive LEDs flash green at
5 s intervals.
The initial start of the operation begins about 8 s after the supply voltage with
the interval time.
6.1.2 Display of the remaining delivery period
During operation, the remaining delivery period can be shown in the display.
f Press and hold the SET button during operation for > 1 s (fl ashing arrow
icon
din the display).
The display shows the remaining delivery time in hours.
>
999h hours appears in the display where the remaining delivery time is
equal or greater than 1000 hours.
358 814-34
358 814-37
