Bosch Rexroth LU 2 - Setting the Delivery Volume in the PULSE Operating Mode

18/54 Function
Bosch Rexroth AG, MIT: LU 2, 3 842 358 814/2017-01
Table 6: Number of deliveries is dependent on the volume of the metered lubricant
to be delivered and the oil container LC 2
Delivery volume
[cm³/pulse]
Number of pulses (delivery) per oil container
LC 2 (Ö LC250)
0.1
2500
0.2
1250
0.3
833
0.4
625
0.5
500
0.6
417
0.7
357
0.8
313
0.9
278
1.0
250
1.2
208
1.4
179
1.6
156
1.8
139
2.0
125
2.2
114
2.4
104
2.6
96
2.8
89
3.0
83
3.5
71
4.0
62
4.5
56
5.0
50
5.5
45
6.0
42
6.5
38
7.0
36
7.5
33
8.0
31
8.5
29
9.0
28
9.5
26
6.2.1 Setting the delivery volume in the PULSE operating mode
The operating mode, the oil container used LC 2 (Ö LC250) and the required
delivery volume per pulse (delivery) are entered via the display using the SET button.
The number of pulses (deliveries) can be taken from Table 6 on page 18.
Please note:
(1 cm³ | 0.9 g lubricant)
