Bosch Rexroth LU 2 - Accumulation Roller Chain: Every 1000 H; Accumulation Roller Chain: Every 2000 H

Function 21/54
3 842 358 814/2017-01, MIT: LU 2, Bosch Rexroth AG
6.3.3 Accumulation roller chain:
Required delivery volume for 2 - 3 g oil/m chain every 1000 h
Fig. 5:
1
)
2019181716151413121110987654321
25
10
5
15
20
0
y [h]
x [m]
358 814-17
Accumulation roller chain: Required delivery volume for 2 - 3 g oil/m chain every 1000 h
6.3.4 Accumulation roller chain:
Required delivery volume for 2 - 3 g oil/m chain every 2000 h
Fig. 6:
1
)
2019181716151413121110987654321
25
10
5
15
20
0
y [h]
x [m]
358 814-17
Accumulation roller chain: Required delivery volume for 2 - 3 g oil/m chain every 2000 h
x [m]: Section length
y [h]: Distance between
the discharging
operations
1
): Delivery volume
each pulse: 0.26 cm
3
x [m]: Section length
y [h]: Distance between
the discharging
operations
1
): Delivery volume
each pulse: 0.26 cm
3
ENGLISH
