Bosch Rexroth LU 2 - Required Delivery Volume

20/54 Function
Bosch Rexroth AG, MIT: LU 2, 3 842 358 814/2017-01
6.3 Required delivery volume
6.3.1 Flat top chain:
Required delivery volume for 2 - 3 g oil/m chain every 1000 h
Fig. 3:
1
)
2
)
2019181716151413121110987654321
11
6
1
y [h]
x [m]
358 814-16
Flat top chain: Required delivery volume for 2 - 3 g oil/m chain every 1000 h
6.3.2 Flat top chain:
Required delivery volume for 2 - 3 g oil/m chain every 2000 h
Fig. 4:
1
)
2
)
2019181716151413121110987654321
11
6
1
y [h]
x [m]
358 814-16
Flat top chain: Required delivery volume for 2 - 3 g oil/m chain every 2000 h
x [m]: Section length
y [h]: Distance between
the discharging
operations
1
): Delivery volume
each pulse: 0.26 cm
3
2
): Delivery volume
each pulse: 0.55 cm
3
x [m]: Section length
y [h]: Distance between
the discharging
operations
1
): Delivery volume
each pulse: 0.26 cm
3
2
): Delivery volume
each pulse: 0.55 cm
3
