Cleaning and maintenance en-us
41
4. Press the locking catches
together and take the coarse filter
upward and out .
5. Clean the filter elements under
running water.
Carefully remove the rim of debris
between the coarse filter and the
fine filter.
6. Put the filter system back together.
Ensure that the locking catches on
the coarse filter click into position.
7. Insert the filter system into the
appliance and turn the coarse filter
clockwise.
‒ Ensure that the arrow markings
match up.
16.5 Cleaning the spray arms
Limescale and soiling in the
dishwashing water may block the
nozzles and bearings on the spray
arms. Clean the spray arms regularly.
1. Unscrew the upper spray arm
and pull down to remove .
2. Pull up the lower spray arm to
remove.
3. Check the outlet nozzles on the
spray arms for blockages under
running water and remove any
foreign objects.
4. Insert the lower spray arm.
a The spray arm clicks into position.
5. Insert the upper spray arm and
screw firmly in place.
