TA Series
Cooling Tower/Boiler Application
Figure 11: Cooling Tower/Boiler Application
COOLING TOWER/BOILER APPLICATION 1. LINE VOLTAGE DISCONNECT (UNIT) 2. LOW VOLTAGE CONTROL CONNECTION 3. P/T PLUGS (Optional) 4. HOSE KITS (Optional) 5. BALL VALVES 6. SUPPLY AND RETURN LINES OF CENTRAL SYSTEM 7. FLEX DUCT CONNECTION 8. HANGING BRACKETS ASSEMBLY 9. THREADED ROD 10. HANGING BRACKET ASSEMBLY NOTE: SEE FIGURE #3 FOR CONDENSATE DRAIN CONNECTION
