AutoDome Modular Camera System Table of Contents | en iii

Bosch Security Systems, Inc. Firmware Update Manual F.01U.097.269 | 1.06 | 2011.09

Table of Contents

1 VG4 Firmware Updates via a TCP/IP Network........................................................................................... 1

1.1 Determining the IP Communications Module .............................................................................................. 1

1.2 Upgrading the IP AutoDome ........................................................................................................................ 2

1.3 Upgrading the VG4 100 Series AutoDome ................................................................................................... 3

1.4 Determining Minimum Requirements (200, 300, 500i Series) .................................................................... 3

1.4.1 Supporting Software Requirements ............................................................................................................ 3

1.4.2 Selecting the Service Pack .......................................................................................................................... 4

1.5 Beginning the Firmware Update Process..................................................................................................... 5

1.6 Updating VG4 100 Series IP AutoDome Firmware....................................................................................... 6

1.7 Updating VG4 200, 300 or 500i Series IP AutoDome Firmware................................................................... 7

1.7.1 Order to Upload Files .................................................................................................................................. 7

1.7.2 Selecting and Uploading Firmware Files ..................................................................................................... 8

1.7.3 Alternate Language Option ........................................................................................................................ 11

1.7.4 Changing the VG4 AutoDome OSD Language............................................................................................ 12

2 VG4 Firmware Updates via the CTFID...................................................................................................... 13

2.1 Upgrading the VG4 100 Series AutoDome ................................................................................................. 13

2.2 Upgrading the VG4 200 or 300 Series AutoDome...................................................................................... 14

2.2.1 Determining Minimum Requirements ........................................................................................................ 14

2.2.2 Selecting the Service Pack ........................................................................................................................ 15

2.3 Hardware Connections .............................................................................................................................. 15

2.3.1 Bilinx Connections..................................................................................................................................... 16

2.3.2 Serial Connections..................................................................................................................................... 16

2.4 Launching the CTFID Software .................................................................................................................. 17

2.4.1 Launching with a Bilinx Connection .......................................................................................................... 17

2.4.2 Launching with a RS232/RS485 Serial Connection .................................................................................. 18

2.5 Uploading VG4 AutoDome Firmware Files ................................................................................................ 20

2.5.1 Uploading a VG4 100 Series AutoDome Service Pack ............................................................................... 20

2.5.2 Uploading a VG4 200 or VG4 300 Series AutoDome Service Pack ............................................................ 21

2.5.3 Order to Upload Files ................................................................................................................................ 22

2.5.4 Selecting and Uploading Firmware Files ................................................................................................... 22

2.5.5 Updating the SC Boot file .......................................................................................................................... 23

2.5.6 Updating the SC Main Files ....................................................................................................................... 26

2.5.7 Additional Language Option ...................................................................................................................... 29

2.5.8 Changing the VG4 AutoDome OSD Language............................................................................................ 30
