RE 30523-B/09.13 | Installation and operation Hydraulics | Bosch Rexroth AG 13/48
Installing the VSPD 2
2.5 Pin assignment of the edge connector
The edge connector is a 64-pin, type G (DIN 41612) connector.
The pin assignment of the edge connector is not fully downward compatible with
existing, older valve amplifiers.
Any changes in the pin assignment were made so as to ensure that damage is avoid-
ed when an older controller card is replaced by a newer one.
The pin assignment is listed in the following tables.
Pin Description Type
2 DI 1 Discrete input
4 DI 2 Discrete input
6 DI 3 Discrete input
8 DI 4 Discrete input
10 DI 5 n. c.
12 DI 6 Discrete input
14 DI 7 n. c.
16 DI 8 n. c.
18 DI 9 Discrete input
20 DO 1 Discrete output
22 OK Discrete output
24 Data +
Local CAN Bus
Input/Output
26 DO 2 Discrete output
28 Data –
Local CAN Bus
Input/Output
30 AO 1 Analog output
32 AO 2 n. c.
Tab. 1 Pin assignment row d
Row d
