Operating the VSPD 4
4.2 Diagnostics test jacks
The diagnostics port on the front panel of the controller card can be used for connect-
ing external diagnosis instruments. You can take measurements via two analog sig-
nals.
4.3 Menu Tree for Setup and Parameters (Option Display)
The following contains an overview of the menus that can be selected using the but-
tons on the HACD controller card. Shown are the parameters and settings that are
available
An overview of the items listed below are shown on the following pages:
Menu tree „Parameter"
Menu tree „Setup“
Menu tree „Valve menu Part 1“
Menu tree „Valve menu Part 2“
Menu tree „Structure"
Menu tree „Command Adjust. Part 1“
Menu tree „Command Adjust. Part 2“
Menu tree „Analog I/O Part 1“
Menu tree „Analog I/O Part 2“
Menu tree „Digital I/O Part 1“
Menu tree „Digital I/O Part 2“
Menu tree „Faults“
For a detailed description of the settings and parameters, please refer to document:
“Starting up the HACD Control Card and Operation of BODAC Software”.
To Next Page
