RE 30523-B/09.13 | Installation and operation Hydraulics | Bosch Rexroth AG 19/48
Commissioning the VSPD controller cards 3
3.2 Installing the software BODAC
The software BODAC, order designation SYS-HACD-BODAC-01/ (material number
R900777335) can also be downloaded on the Internet. This software is used for initial
commissioning and convenient operation of the controller card. You can use it to
make all the required settings for the optimum operation of your VSPD controller card.
The functions, menus and program windows of the software are matched to your
controller card. This makes the operation of the software very easy.
Installation requirements
100% IBM compatible PC with the following minimum requirements:
200 MHz Pentium processor (or comparable)
32 MB working memory (RAM)
VGA graphic card, minimum resolution: 800x600 pixels
Hard drive with minimum 2 MB available space
CD-ROM drive
Mouse
Free serial interface
Operating system: Windows 2000/ XP
TM
.
When these requirements are met you can install the software BODAC as described
in the next chapter.
BODAC setup routine
Start the setup routine for the installation of the software BODAC with the file "Set-
up.exe".
Installing the BODAC software:
¾ Insert CD-ROM and navigate to "Setup.exe" file.
¾ Double-click on “Setup.exe“.
9 The setup program will load and show a the start screen.
¾ Follow the instruction on screen to run through the setup routine.
9 The software BODAC is now installed.
