6/48 Bosch Rexroth AG | Hydraulics Installation and operation | RE 30523-B/09.13
1 General
Signs and symbols used
The following signs and symbols are used in these instructions:
¾ Action symbol: The text following this symbol describes actions. The text under
this sign describes activities that must be carried out in the given order.
9 Result symbol: The text following this symbol describes the results of an action.
Following this symbol you will find notes and useful tips for optimal use of
the controller card.
Special safety notes are provided at the relevant locations. These are indicated by the
following symbols.
General hazard
This sign is placed in front of activities which represent a potential
hazard to persons and/or extensive damage to equipment.
If the source of the hazard can be exactly defined, the corresponding pictogram is
used.
Hazard of electric power
This sign is placed in front of activities which represent a potential
hazard to persons and/or extensive damage to equipment due to high
voltage.
Damage to property
This sign precedes activities, which involve a risk of damage to prop-
erty.
1.2 Scope of supply
The equipment is packed in anti-static packaging to protect the controller card from
electrostatic discharge. Please also observe the notes at the top of the packaging.
Included in the shipment:
Controller card VSPD
RE data sheet RE 30 523-B
Warning signs
