16/48 Bosch Rexroth AG | Hydraulics Installation and operation | RE 30523-B/09.13
2 Installing the VSPD
Pin Description Type
2 DO 7 n. c.
4 SSI Clk + n. c.
6 SSI Clk - n. c.
8
SSI Data+ /
INC Ua1
n. c.
10
SSI Data - /
INC /Ua1
n. c.
12 Ua2 n. c.
14 /Ua2 n. c.
16 Ua0 n. c.
18 /Ua0 n. c.
20 L2O- n. c.
22 L2I- n. c.
24 L2I+ n. c.
26 L2O+ n. c.
28 GND_CAN n. c.
30 CANL n. c.
32 CANH n. c.
Tab. 4 Pin assignment row f
