30/48 Bosch Rexroth AG | Hydraulics Installation and operation | RE 30523-B/09.13
4 Operating the VSPD
Fig. 13 Menu tree „Analog I/O Part 1“
Level 1 Level 2 Level 3 Level 4 Level 5
Analog I/O
Press “ENTER + ESC“
Inputs
to go to the configura-
tion menu
Voltage (b14/b16)
Type
+/-10 Volts
[0~+10] Volts
Range
+/-100 %
[0~+100] %
Min. Value V
[-11.00~+11.00] V
Max. Value V
[-11.00~+11.00] V
Min. Fault V
[-11.0~+11.0] V
Max. Fault V
[-11.0~+11.0] V
Max. Unit
100.0 s
Current (b22/b24)
Type
[+4~+20] mA
Range
+/-100 %
[0~+100] %
Min. Value mA
[-2.00~+22.00] mA
Max. Value mA
[-2.00~+22.00] mA
Min. Fault mA
[-2.0~+22.0] mA
Max. Fault mA
[-2.0~+22.0] mA
Max. Unit
100.0 s
Ramp+ (b6/b8)
Type
[0~+10] Volts
[+4~+20] mA
Range
[0~+100] %
Min. Value V
[-11.00~+11.00] V
Min. Value mA
[-2.00~+22.00] mA
