RE 30523-B/09.13 | Installation and operation Hydraulics | Bosch Rexroth AG 33/48
Operating the VSPD 4
Fig. 16 Menu tree „Digital I/O Part 2“
Level 1 Level 2 Level 3 Level 4 Level 5
DO4
Type
Off
Sol. B active
Sol. A active
Ramp done
Error analog I/O
ABS(actual)<= WIN
FAULT STATUS
DO4 Window
[-100.00~+100.00]
DO4 Debounce
[+0.01~+60.00]
DO4 zero-active
Off
On
DO5
Type
Off
Sol. B active
Sol. A active
Ramp done
Error analog I/O
ABS(actual)<= WIN
FAULT STATUS
DO5 Window
[-100.00~+100.00]
DO5 Debounce
[+0.01~+60.00]
DO5 zero-active
Off
On
DO6
Type
Off
Sol. B active
Sol. A active
Ramp done
Error analog I/O
ABS(actual)<= WIN
FAULT STATUS
DO6 Window
[-100.00~+100.00]
DO6 Debounce
[+0.01~+60.00]
DO6 zero-active
Off
On
