Inspection and maintenance
Greenstar 8000 Style – 6720883855 (2019/01)
56
8.4 Component access
Removing bottom panel
1. Push in the clip securing the bottom panel.
2. Pull bottom panel sidewards to release from service position and
remove.
Fig. 72 Removing bottom panel
Removing front cover
1. Remove screw from bottom of front panel
2. Push in the green clips securing both sides the outer case.
3. Pull bottom of front cover forwards and upwards to release the clip on
top of the boiler and remove outer case.
Fig. 73 Removing outer case
8.5 Fan pressure test
NOTICE:
Fan pressure test
▶ The appliance must be running at maximum output in test mode for
the fan pressure test, ( chapter 6.4).
Fig. 74 Fan pressure test point
This test is to determine if the heat exchanger requires cleaning or
attention.
Fan pressure test reading.
▶ The pressure reading will be in negative values.
0010023671-001
2.
1.
0010019013-001
2.
1. 1.
0 010 007 177-001
