Bose 1800

14
PART LIST
Item
Number
Description Part
Number
Note
A1 Preload Network 102666 6
RT-1, RT-2 Thermal Cut-Out 102440 6
¥ RCA Jack 102784 6, 9
Q10-23 Screw, 6/32 x 1/2 Stainless Steel 106348 6
Q10-23 Washer 103032 6
Q10-23 Plastic Insulator 102901 6
Q10-23 Nut, Brass, 6/32 x 5/16 x 1/8 103016 6
Q4, 5 Heat Sink Assy 102571 6
¥ Top Wiring Harness 102929-1 1, 7, 9
¥ Bottom Wiring Harness 103281-1 1, 7, 9
¥ Top Wiring Harness 103365 1, 8, 9
¥ Bottom Wiring Harness 103366 1, 8, 9
¥ Audio Cable 102838 9
S1 Toggle Switch, ON/OFF 103291 8
S1 Switch, ON/OFF 102740 7
S2 Input Switch 102576 7
S3 Speaker Switch 103400 7
J3, 4 (J5, 6 1801 ) Phone Jack 102704
R5, 6 Gain Control, 100kΩ 102406 7
R5, 6 Gain Control, 100kΩ 103260 8
1 Indicator Lens, White 103479-1
2 Indicator Lens, Red 103479-0
3 Lens Housing 103478
4 Front Handle 121914 8
5 Knob 128907 7
5 Knob 121911 8
M1, 2 VU Meters 102570 7
B1-4 Meter Lamps 103063 7
B5, 6, 7
L.E.D / Bose
®
Logo Lamp 1847
102580 7
B8 Thermal Cutout Indicator 102582 7
K1 Start-up Relay 102818
6 Accy Outlet 107558
7 Line Cord 103441
T1 Transformer 102434 1, 7
T1 Transformer (110v) 110185 1
T1 Transformer (220v) 112669 1
Main Part List (per figures 1-7)
