Bose 1800

15
PART LIST
Main Part List (per figures 1-7)
Item
Number
Description Part
Number
Note
8 Rubber Foot 121929
F1 Fuse (110v)15A, 1 1/4 x 1/4Slo-Blo 103608
F1 Fuse (220v) 8A, 5 x 20mm 108190-800
F1 Fuse (220v) 7A, 1 1/4 x 1/4Slo-Blo 103609
¥ Fuse Cap for 1 1/4 x 1/4 109484 9
¥ Fuse Cap for 5 x 20mm 109493 9
9 Front Panel Assy 103380 1, 7
10 Front Panel Assy 121910 1, 8
11¥ Rear Panel Assy 103282 1, 7, 9
12 Rear Panel Assy 103266 1, 8
13 Amp PCB Complete 102735-1 1
14 L.E.D Board Complete 102751 1
Carton and Fillers 103268
15 Heat Sink Side 102536 1
16 Heat Sink Corner 102474 1
17 Top Cover 102544 1, 7
18 Top Cover 121930 1, 8
19 Screw Heat Sink 103041
¥ Accessory Kit 102745 1, 7, 9
¥ Accessory Kit 103361 1, 8, 9
20 Black Binding Post 109068-0
21 Red Binding Post 109068-2
22 Blue Binding Post 109068-6
23 Black Binding Post Base 109069-0
24 Fuse Holder 109485
25 Strain Relief 102708
