Bose 1800

16
PART LIST
Resistors
Reference
Designator
Description Part
Number
Note
R1-4 1MΩ, 1/2W, 10% 102944-105 3
R2 8.2kΩ, 1/2W, 10% 104064-822
R3 3kΩ, 2W, 10% 108676-302
R9, 17 6.19Ω, 1/4W, 1% 104095-6191
R11 1.5kΩ, 1/4W, 1% 104095-1501
R12, 51, 53 340Ω, 1/4W, 1% 104095-3400
R13 100Ω, Bias Pot 102832
R18, 20, 48 23.7kΩ, 1/4W, 1% 104095-2372
R25, 26 182Ω, 1/4W, 1% 104095-1820
R31-36, 41-46 0.8Ω, Wirewound, 3W, 5% 102394
R37-39 0.4Ω, Wirewound, 6W, 5% 102395
R47 4.7Ω, 2W, 5% 102393
R50 470Ω, 1/2W, 5% 102942-471
R52, 54 10kΩ, 1/4W, 1% 104095-1002
R55, 57 100kΩ, 1/4W, 1% 104095-1003
R56 680Ω, 1/2W, 5% 102942-681
R1,3,101,103 5.1kΩ, 1W, 5% 104064-512 2
R2,4,10,13,16,19
102,104,107,110
113,116,119
150Ω 1/2W, 5% 102942-151
2
R5,105 3.6kΩ, 1W, 5% 104064-362 2
R6,9,106,109 2kΩ, 1/2W, 5% 102942-202 2
R8,108 8.2kΩ, 1W, 5% 104064-822 2
R11,111 12kΩ, 1/2W, 5% 102942-123 2
R12,15,18,112,
115,118
1kΩ, 1/2W, 5% 102942-102
2
R14,114 24kΩ, 1/2W, 5% 102942-243 2
R17,117 43kΩ, 1/2W, 5% 102942-433 2
R20,120 15kΩ, 1/2W, 5% 102942-153 2
R21,121 120Ω, 1/2W, 5% 102942-121 2
R22,122 18kΩ, 1/2W, 5% 102942-183 2
