ELECTRICAL PART LIST
Resistors (continued)
Reference Designator Description Part Number Note
R147 220 OHM, 0805, 1/10W, 5% 133626-2215
R148 10.0K, 0805, 1/10W, 5% 133626-1035
R152 4.7K, 0805, 1/10W, 5% 133626-4725
R161 100K, 0805, 1/10W, 1% 133625-1003
R162 100K, 0805, 1/10W, 1% 133625-1003
R163 100K, 0805, 1/10W, 1% 133625-1003
R164 100K, 0805, 1/10W, 1% 133625-1003
R165 100K, 0805, 1/10W, 1% 133625-1003
R166 330 OHM, 0805, 1/10W, 5% 133626-3315
R200 1.00K, 0805, 1/10W, 1% 133625-1001
R201 100K, 0805, 1/10W, 1% 133625-1003
R202 1.00K, 0805, 1/10W, 1% 133625-1001
R203 100K, 0805, 1/10W, 1% 133625-1003
R204 1.00K, 0805, 1/10W, 1% 133625-1001
R205 100K, 0805, 1/10W, 1% 133625-1003
R208 150 OHM, 0805, 1/10W, 1% 133625-1500
R210 150 OHM, 0805, 1/10W, 1% 133625-1500
R211 100K, 0805, 1/10W, 1% 133625-1003
R212 150 OHM, 0805, 1/10W, 1% 133625-1500
R213 100K, 0805, 1/10W, 1% 133625-1003
R216 150 OHM, 0805, 1/10W, 1% 133625-1500
R217 100K, 0805, 1/10W, 1% 133625-1003
R218 150 OHM, 0805, 1/10W, 1% 133625-1500
R219 100K, 0805, 1/10W, 1% 133625-1003
R242 51.1K, 0805, 1/10W, 0.1% 181896-5112
R243 220 OHM, 0805, 1/10W, 5% 133626-2215
R244 16.9K, 0805, 1/10W, 0.1% 181896-1692
R252 4.7K, 0805, 1/10W, 5% 133626-4725
R262 100K, 0805, 1/10W, 1% 133625-1003
R263 100K, 0805, 1/10W, 1% 133625-1003
R264 100K, 0805, 1/10W, 1% 133625-1003
R300 5.6K, 0805, 1/10W, 5% 133626-5625
R301 24K, 0805, 1/10W, 5% 133626-2435
R302 10 OHM, 0805, 1/10W, 5% 133626-1005
R303 5.6K, 0805, 1/10W, 5% 133626-5625
R304 2.2K, 0805, 1/10W, 5% 133626-2225
R305 24K, 0805, 1/10W, 5% 133626-2435
R309 2.2K, 0805, 1/10W, 5% 133626-2225
R311 22K, 0805, 1/10W, 5% 133626-2235
R312 4.7K, 0805, 1/10W, 5% 133626-4725
R313 10.0K, 0805, 1/10W, 5% 133626-1035
R314 10 OHM, 0805, 1/10W, 5% 133626-1005 5
R314 100 OHM, 0805, 1/10W, 5% 133626-1015
R315 4.7K, 0805, 1/10W, 5% 133626-4725
R316 1.00K, 0805, 1/10W, 5% 133626-1025
R317 1.60K, 0805, 1/10W, 5% 133626-1625
R318 620 OHM, 0805, 1/10W, 5% 133626-6215
R319 22 OHM, 0805, 1/10W, 5% 133626-2205
R320 9.1K, 0805, 1/10W, 5% 133626-9125
R321 4.7K, 0805, 1/10W, 5% 133626-4725 6
R321 47.0K, 0805, 1/10W, 5% 133626-4735
R322 1.2K, 0805, 1/10W, 5% 133626-1225
R323 33 OHM, 1206, 1/8W, 5% 124895-3305
R324 3.3K, 0805, 1/10W, 5% 133626-3325
