ELECTRICAL PART LIST
Resistors (continued)
Reference Designator Description Part Number Note
R325 2.7K, 0805, 1/10W, 5% 133626-2725 5
R326 8.2K, 0805, 1/10W, 5% 133626-8225 5
R326 3.09K, 0805, 1/10W, 1% 133625-3091
R328 12K, 0805, 1/10W, 5% 133626-1235
R329 5.11K, 0805, 1/10W, 1% 133625-5111
R330 10 OHM, 0805, 1/10W, 5% 133626-1005 5
R330 51 OHM, 0805, 1/10W, 5% 133626-5105
R331 10.0K, 0805, 1/10W, 5% 133626-1035 5
R332 1.00K, 0805, 1/10W, 5% 133626-1025
R333 120 OHM, 0805, 1/10W, 5% 133626-1215
R334 330 OHM, 0805, 1/10W, 5% 133626-3325 5
R334 2.32K, 0805, 1/10W, 1% 133625-2321
R335 18.0K, 0805, 1/10W, 5% 133626-1835 5
R335 499 OHM, 0805, 1/10W, 1% 133625-4990
R336 390 OHM, 0805, 1/10W, 5% 133626-3915 6
R336 560 OHM, 0805, 1/10W, 5% 133626-5615 5
R336 2.32K, 0805, 1/10W, 1% 133625-2321
R337 330 OHM, 0805, 1/10W, 5% 133626-3325 5
R337 499 OHM, 0805, 1/10W, 1% 133625-4990
R338 22K, 0805, 1/10W, 5% 133626-2235 5
R338 330 OHM, 0805, 1/10W, 5% 133626-3315
R339 330 OHM, 0805, 1/10W, 5% 133626-3325 5
R339 2.32K, 0805, 1/10W, 1% 133625-2321
R340 18.0K, 0805, 1/10W, 5% 133626-1835 5
R341 390 OHM, 0805, 1/10W, 5% 133626-3915 6
R341 560 OHM, 0805, 1/10W, 5% 133626-5615 5
R342 330 OHM, 0805, 1/10W, 5% 133626-3325 5
R343 22K, 0805, 1/10W, 5% 133626-2235 5
R344 1.05K, 0805, 1/10W, 1% 133625-1051
R346 4.7K, 0805, 1/10W, 5% 133626-4725
R347 4.7K, 0805, 1/10W, 5% 133626-4725
R348 5K OHM, POT, RTRY, 30%, 1/2W 177494-203 6
R348 20K OHM, POT, RTRY, 30%, 1/2W 177494-502
R349 10K OHM, POT, RTRY, 30%, 1/2W 177494-103 6
R350 1.00K, 0805, 1/10W, 5% 133626-1025
R351 4.7K, 0805, 1/10W, 5% 133626-4725
R352 1.00K, 0805, 1/10W, 5% 133626-1025
R353 4.7K, 0805, 1/10W, 5% 133626-4725 6
R353 47.0K, 0805, 1/10W, 5% 133626-4735
R354 10.0K, 0805,1/10W, 5% 133626-1035
R355 6.80K, 0805, 1/10W, 5% 133626-6825
R357 10.0K, 0805,1/10W, 5% 133626-1035 5
R359 4.02K, 0805, 1/10W, 1% 133625-4021
R360 100 OHM, 0805, 1/10W, 5% 133626-1015 5
R360 2.32K, 0805, 1/10W, 1% 133625-2321
R361 100 OHM, 0805, 1/10W, 5% 133626-1015 5
R361 330 OHM, 0805, 1/10W, 5% 133626-3315
R362 100 OHM, 0805, 1/10W, 5% 133626-1015 5
R363 100 OHM, 0805, 1/10W, 5% 133626-1015 5
R401 100 OHM, 0805, 1/10W, 5% 133626-1015
R402 10.0K, 0805, 1/10W, 5% 133626-1035
R403 10.0K, 0805, 1/10W, 5% 133626-1035
R404 1.00K, 0805, 1/10W, 5% 133626-1025
R405 1.00K, 0805, 1/10W, 5% 133626-1025
