ELECTRICAL PART LIST
Resistors (continued)
ESP-88C Chassis 4x4 Series II PCB Assembly
Reference
Designator
Description Vendor Part Number Vendor Name Note
R448 6.8k RK73H1JTD6.8KF KOA 4
R449 10k RK73H1JTD10KF KOA 4
R450 6.8k RK73H1JTD6.8KF KOA 4
R451 6.8k RK73H1JTD6.8KF KOA 4
R452 10k RK73H1JTD10KF KOA 4
R453 6.8k RK73H1JTD6.8KF KOA 4
R454 10k RK73H1JTD10KF KOA 4
R455 10k RK73H1JTD10KF KOA 4
R456 10k RK73H1JTD10KF KOA 4
R457 10 Ohm RK73H1JTD10RF KOA 4
R458 10 Ohm RK73H1JTD10RF KOA 4
R459 47 Ohm RK73H1JTD47RF RHOM 4
R460 47 Ohm RK73H1JTD47RF RHOM 4
R461 4.7k RK73H1JTD4.7KF KOA 4
R462 4.7k RK73H1JTD4.7KF KOA 4
R463 33 Ohm RK73H1JTD33RF KOA 4
R464 33 Ohm RK73H1JTD33RF KOA 4
R465 1.5k RK73H1JTD1.5KF KOA 4
R466 1.5k RK73H1JTD1.5KF KOA 4
R467 1.8k RK73H1JTD1.8KF KOA 4
R468 2.2k RK73H1JTD2.2KF KOA 4
R469 10k RK73H1JTD10KF KOA 4
R470 1.8k RK73H1JTD1.8KF KOA 4
R471 10k RK73H1JTD10KF KOA 4
R472 2.2k RK73H1JTD2.2KF KOA 4
R473 4.7k RK73H1JTD4.7KF KOA 4
R474 10k RK73H1JTD10KF KOA 4
R475 100 Ohm RK73H1JTD100RF KOA 4
R476 100 Ohm RK73H1JTD100RF KOA 4
R477 12k RK73H1JTD12KF KOA 4
R478 2.2k RK73H1JTD2.2KF KOA 4
R479 100 Ohm RK73H1JTD100RF KOA 4
R480 100 Ohm RK73H1JTD100RF KOA 4
R481 12k RK73H1JTD12KF KOA 4
R482 2.2k RK73H1JTD2.2KF KOA 4
R501 0 Ohm RK73Z1JTD 0RJ KOA 4
R502 OPEN NOT USED NOT USED 4
R503 OPEN NOT USED NOT USED 4
R504 10k RK73H1JTD10KF KOA 4
R505 10k RK73H1JTD10KF KOA 4
R506 470 Ohm RK73H1JTD470RF KOA 4
R507 470 Ohm RK73H1JTD470RF KOA 4
R508 470 Ohm RK73H1JTD470RF KOA 4
R509 470 Ohm RK73H1JTD470RF KOA 4
R510 2.7k RK73H1JTD2.7KF KOA 4
R511 2.7k RK73H1JTD2.7KF KOA 4
