ELECTRICAL PART LIST
Resistors (continued)
ESP-88C Chassis 4x4 Series II PCB Assembly
Reference
Designator
Description Vendor Part Number Vendor Name Note
R615 0 Ohm RK73Z1JTD 0RJ KOA 4
R616 0 Ohm RK73Z1JTD 0RJ KOA 4
R617 0 Ohm RK73Z1JTD 0RJ KOA 4
R618 0 Ohm RK73Z1JTD 0RJ KOA 4
R619 0 Ohm RK73Z1JTD 0RJ KOA 4
R620 OPEN NOT USED NOT USED 4
R621 OPEN NOT USED NOT USED 4
R622 0 Ohm RK73Z1JTD 0RJ KOA 4
R623 0 Ohm RK73Z1JTD 0RJ KOA 4
R624 0 Ohm RK73Z1JTD 0RJ KOA 4
R625 0 Ohm RK73Z1JTD 0RJ KOA 4
R626 0 Ohm RK73Z1JTD 0RJ KOA 4
R627 0 Ohm RK73Z1JTD 0RJ KOA 4
R628 0 Ohm RK73Z1JTD 0RJ KOA 4
R629 0 Ohm RK73Z1JTD 0RJ KOA 4
R630 0 Ohm RK73Z1JTD 0RJ KOA 4
R631 0 Ohm RK73Z1JTD 0RJ KOA 4
R632 0 Ohm RK73Z1JTD 0RJ KOA 4
R633 0 Ohm RK73Z1JTD 0RJ KOA 4
R634 0 Ohm RK73Z1JTD 0RJ KOA 4
R635 0 Ohm RK73Z1JTD 0RJ KOA 4
R636 0 Ohm RK73Z1JTD 0RJ KOA 4
R637 0 Ohm RK73Z1JTD 0RJ KOA 4
R638 OPEN NOT USED NOT USED 4
R639 OPEN NOT USED NOT USED 4
R700 0 Ohm RK73Z1JTD 0RJ KOA 4
R701 OPEN NOT USED NOT USED 4
R702 OPEN NOT USED NOT USED 4
R703 OPEN NOT USED NOT USED 4
R704 33 Ohm RK73H1JTD33RF KOA 4
R705 33 Ohm RK73H1JTD33RF KOA 4
R706 330 Ohm RK73H1JTD330RF KOA 4
R707 330 Ohm RK73H1JTD330RF KOA 4
R708 330 Ohm RK73H1JTD330RF KOA 4
R709 330 Ohm RK73H1JTD330RF KOA 4
R710 330 Ohm RK73H1JTD330RF KOA 4
R711 330 Ohm RK73H1JTD330RF KOA 4
R712 330 Ohm RK73H1JTD330RF KOA 4
R713 330 Ohm RK73H1JTD330RF KOA 4
R714 10k RK73H1JTD10KF KOA 4
R716 10k RK73H1JTD10KF KOA 4
R717 33 Ohm RK73H1JTD33RF KOA 4
R718 33 Ohm RK73H1JTD33RF KOA 4
R719 330 Ohm RK73H1JTD330RF KOA 4
R720 330 Ohm RK73H1JTD330RF KOA 4
R721 330 Ohm RK73H1JTD330RF KOA 4
