ELECTRICAL PART LIST
Resistors (continued)
ESP-88C Chassis 4x4 Series II PCB Assembly
Reference
Designator
Description Vendor Part Number Vendor Name Note
R722 330 Ohm RK73H1JTD330RF KOA 4
R723 330 Ohm RK73H1JTD330RF KOA 4
R724 330 Ohm RK73H1JTD330RF KOA 4
R725 330 Ohm RK73H1JTD330RF KOA 4
R726 330 Ohm RK73H1JTD330RF KOA 4
R727 OPEN NOT USED NOT USED 4
R728 0 Ohm RK73Z1JTD 0RJ KOA 4
R729 OPEN NOT USED NOT USED 4
R730 10k RK73H1JTD10KF KOA 4
R731 10k RK73H1JTD10KF KOA 4
R732 10k RK73H1JTD10KF KOA 4
R733 10k RK73H1JTD10KF KOA 4
R734 10k RK73H1JTD10KF KOA 4
R735 OPEN NOT USED NOT USED 4
R736 33 Ohm RK73H1JTD33RF KOA 4
R737 33 Ohm RK73H1JTD33RF KOA 4
R738 OPEN NOT USED NOT USED 4
R739 OPEN NOT USED NOT USED 4
R740 0 Ohm RK73Z1JTD 0RJ KOA 4
R741 330 Ohm RK73H1JTD330RF KOA 4
R742 330 Ohm RK73H1JTD330RF KOA 4
R743 0 Ohm RK73Z1JTD 0RJ KOA 4
R744 OPEN NOT USED NOT USED 4
R745 OPEN NOT USED NOT USED 4
R746 4.7k RK73H1JTD4.7KF KOA 4
R747 33 Ohm RK73H1JTD33RF KOA 4
R748 33 Ohm RK73H1JTD33RF KOA 4
R749 OPEN NOT USED NOT USED 4
R750 OPEN NOT USED NOT USED 4
R751 0 Ohm RK73Z1JTD 0RJ KOA 4
RA703 RES ARRAY, 33 Ohm CN1J4KTD33RJ KOA 4
RA704 RES ARRAY, 33 Ohm CN1J4KTD33RJ KOA 4
RA705 RES ARRAY, 33 Ohm CN1J4KTD33RJ KOA 4
RA706 RES ARRAY, 10k MNR15E0RPJ103 RHOM 4
