Bose FreeSpace IZA 190-HZ Service Manual

37
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ DSP PCB Assembly
Resistors (continued)
Reference
Designator
Description
V
endo
r
Part
Number
Note
R97 47K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/, S 4723-473A+P-
R
4
R98 820
R
, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-821A+P-
R
4
R99 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R110 820R, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-821A+P-R 4
R116 12K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-123A+P-
R
4
R117 12K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-123A+P-R 4
R118 1R, RMG, 1/16W, , 5%, 0603 4723-1R0J+P 4
R123 1R, RMG, 1/16W, 5%, 0603 4723-1R0J+P 4

Capacitors
Reference
Designator
Description
V
endo
r
Part
Number
Note
CAP1 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
CAP2 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
CAP3 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
CAP4 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
CAP5 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
CAP6 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
CAP7 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
CAP8 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C1 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C2 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C3 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C4 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C5 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C6 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C7 22UF, CE, 6.3V, , 20%, 4.3X5.4, SM, 356722209R2 157B-226M+3-HJI 4
C8 22UF, CE, 6.3V, , 20%, 4.3X5.4, SM, 356722209R2 157B-226M+3-HJI 4
C9 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C10 100uF, CE, 10V, , 20%, SM, 6.3X5.4 157C-107M+3-LJ 4
C11 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C12 220UF, CE, 6.3V, , 20%, SM, 6.3X5.3, NOVER 157B-227M+3-LJU 4
C13 22UF, CE, 6.3V, , 20%, 4.3X5.4, SM, 356722209R2 157B-226M+3-HJI 4
C14 4.7UF, CC, 6.3V, 10%, 0603 150B-475K+P-AC 4
C15 22UF, CE, 6.3V, , 20%, 4.3X5.4, SM, 356722209R2 157B-226M+3-HJI 4
C16 22UF, CE, 6.3V, , 20%, 4.3X5.4, SM, 356722209R2 157B-226M+3-HJI 4
C17 22UF, CE, 6.3V, , 20%, 4.3X5.4, SM, 356722209R2 157B-226M+3-HJI 4
C18 22UF, CE, 6.3V, , 20%, 4.3X5.4, SM, 356722209R2 157B-226M+3-HJI 4
C19 4.7UF, CC, 6.3V, 10%, 0603 150B-475K+P-AC 4
C20 4.7UF, CC, 6.3V, 10%, 0603 150B-475K+P-AC 4
C21 22UF, CE, 6.3V, , 20%, 4.3X5.4, SM, 356722209R2 157B-226M+3-HJI 4
C22 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C23 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C24 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C25 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C26 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C27 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
