Bose FreeSpace IZA 190-HZ Service Manual

60
Resistors
ELECTRICAL PART LIST
FreeSpace
®
ZA 190-HZ Rear I/O Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R501 100R, RMG, 1/16W, 1%, 0603 4723-101A+
P
4
R502 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R503 3.3K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-332A+P-R 4
R504 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R505 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R506 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R507 0R, RMG, 1/16W, 1%, 0603 4723-000A+
P
4
R508 100K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-104A+P-R 4
R509 47K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/,
SAMSUNG
4723-473A+P-R 4
R510 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R511 82K, RMG, 1/16W, 5%, 0603/1608 4723-823J+
P
4
R512 36K, RMG, 1/16W, 1%, 0603 4723-363A+P 4
R513 3.9K, RMG, 1/16W, 1%, 0603/1608 4723-392A+P 4
R514 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-
R
4
R515 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-
R
4
R516 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+
P
4
R517 11K, RMG, 1/16W, 1%, 0603/1608 4723-113A+
P
4
R518 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R519 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R520 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R521 47K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/,
SAMSUNG
4723-473A+P-
R
4
R522 470R, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-471A+P-R 4
R523 4.7M, RMG, 1/10W, 1%, 0603 4720-475A+P 4
R524 270K, RMG, 1/16W, 1%, 0603 4723-274A+
P
4
R525 200K, RMG, 1/16W, 1%, 0603/1608 4723-204A+P 4
R526 82K, RMG, 1/16W, 5%, 0603/1608 4723-823J+P 4
R527 270R, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-271A+P-R 4
R528 270R, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-271A+P-R 4
R529 560K, RMG, 1/16W, 1%, 0603/1608 4723-564A+P 4
R530 470R, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-471A+P-R 4
R531 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+
P
4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
