Bose FreeSpace IZA 190-HZ Service Manual

51
Integrated Circuits
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ MIC PCB Assembly
Miscellaneous
FreeSpace IZA 190-HZ Output PCB Assembly
Inductors
Reference
Designator
Description
V
endor Part
Number
Note
L1 FERRITE, COIL, 1.4M, 28%, BL15.2, RL, P5 1807-142T5 4

Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
P1 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
P2 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
P3 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231 4
SP1 SOCKET, M, 3P, P5, 300V, 15A, GREEN 2113-3368 4

Reference
Designator
Description
V
endor Part
Number
Note
U102 NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890 4
U101 TL072CDR, DUAL, J-FET, INPUT, OP-
A
MP 3130-8020 4

Reference
Designator
Description
V
endor Part
Number
Note
Z142 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111 480M-1110 4
Z143 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111 480M-1110 4
J1 CONNECTOR, 9P, 2MM 2102-090S 4
J100 JACK, MIC, PHONE, COMBO, 11P, NCJ10FI-H-0,
NE
2113-3213 4
CON GND WIRE, GROUND, 1P, L=58, GREEN/YRL, RING 7012-9970 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
