Bose FreeSpace IZA 190-HZ Service Manual

41
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ Rear Panel I/O PCB Assembly
Resistors
Reference
Designator
Description
V
endo
r
Part
Number
Note
R1 0R, RMG, 1/16W, 1%, 0603 4723-000A+
P
4
R100 0R, RMG, 1/8W, 1%, 1206 4721-000A+6 4
R101 0R, RMG, 1/8W, 1%, 1206 4721-000A+6 4
R171 5.1K, RMG, 1/16W, 5%, 0603/1608 4723-512J+P 4
R173 5.1K, RMG, 1/16W, 5%, 0603/1608 4723-512J+P 4
R174 5.1K, RMG, 1/16W, 5%, 0603/1608 4723-512J+P 4
R175 5.1K, RMG, 1/16W, 5%, 0603/1608 4723-512J+P 4
R200 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4
R201 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R202 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R203 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R204 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R205 100R, RMG, 1/16W, 1%, 0603 4723-101A+
P
4
R206 1K, RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P 4
R207 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R208 1K, RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+
P
4
R209 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R210 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R211 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4
R212 100R, RMG, 1/16W, 1%, 0603 4723-101A+
P
4
R213 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4
R214 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4
R215 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R216 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R217 3K, RMG, 1/16W, 1%, 0603 4723-302A+P 4
R218 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R219 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R220 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R223 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R225 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4
R226 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R227 1K, RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P 4
R228 1K, RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P 4
R229 9.76K, RMG, 1/16W, 1%, 0603 4723-9761+P 4
R230 4.99K, RMG, 1/16W, 1%, 0603 4723-4991+P 4
R231 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R232 2.2K, RMG, 1/16W, 5%, 0603, HK, RESISTOR/SA 4723-222J+P-R 4
R233 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R234 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R235 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R236 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R237 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R238 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R239 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4
R240 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R241 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-
R
4
R242 10K, RMG, 1/16W, 1%, 0603, HK, RESISTOR/SA 4723-103A+P-R 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
