Bose FreeSpace IZA 190-HZ Service Manual

39
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ DSP PCB Assembly
Capacitors (continued)
Reference
Designator
Description
V
endo
r
Part
Number
Note
C75 270PF, CC, 50V, , 10%, 0603, 1x2 150F-271K+
P
-AC 4
C76 560PF, CC, 50V, 10%, 0603/1608, 1X2 150F-561K+
P
-AC 4
C77 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C78 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C79 0.1U
F
, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C80 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C81 0.1UF, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C82 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C83 33PF, CC, 50V, 5%, 0603/1608, 1X2 150F-330J+P-AC 4
C84 33PF, CC, 50V, 5%, 0603/1608, 1X2 150F-330J+P-AC 4
C85 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C86 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C87 0.1U
F
, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C88 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C89 100PF, CC, 50V, , 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C90 0.1U
F
, CC, 100V, 10%, 0603 150H-104K+P-AC 4
C91 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C92 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C93 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C94 0.1U
F
, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C95 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C96 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C97 22pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-220J+P-AC 4
C98 4.7U
F
, CC, 10V, 10%, 0805, X7R 150C-475K+J-BD 4
C99 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C118 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C124 0.1U
F
, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C126 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4

Inductors
Reference
Designator
Description
V
endor Part
Number
Note
L1 FERRITE, BEAD, SMD,
A
CB453215, 125 1802-0630+0 4
L2 FERRITE, BEAD, SMD,
A
CB453215, 125 1802-0630+0 4
L3 FERRITE, BEAD, SMD, ACB453215, 125 1802-0630+0 4
L4 FERRITE, BEAD, SMD, ACB453215, 125 1802-0630+0 4
L5 FERRITE, BEAD, SMD,
A
CB453215, 125 1808-0878+0 4
L6 FERRITE, BEAD, SMD, ACB453215, 125 1808-0878+0 4
L7 FERRITE, BEAD, SMD, ACB453215, 125 1808-0878+0 4
L8 FERRITE, BEAD, SMD, ACB453215, 125 1808-0878+0 4
L9 FERRITE, BEAD, SMD,
A
CB453215, 125 1808-0878+0 4
L10 FERRITE, BEAD, SMD, ACB453215, 125 1808-0878+0 4
L11 FERRITE, BEAD, SMD, ACB453215, 125 1808-0878+0 4
L12 FERRITE, BEAD, SMD, ACB453215, 125 1808-0878+0 4
L13 FERRITE, BEAD, SMD,
A
CB453215, 125 1808-0878+0 4
L14 FERRITE, BEAD, SMD, ACB453215, 125 1808-0878+0 4
L15 FERRITE, BEAD, SMD, ACB453215, 125 1808-0878+0 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
