Bose FreeSpace IZA 190-HZ Service Manual

43
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ Rear Panel I/O PCB Assembly
Capacitors (continued)
Reference
Designator
Description
V
endo
r
Part
Number
Note
C216 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C217 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C218 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C219 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+P-AC 4
C220 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C221 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C223 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C224 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C225 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+
P
-AC 4
C226 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C227 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+P-AC 4
C228 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C229 470PF, CC, 50V, 5%, 0603 150F-471J+P-AC 4
C231 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C233 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C234 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+
P
-AC 4
C235 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C236 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C237 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C238 470PF, CC, 50V, 5%, 0603 150F-471J+P-AC 4
C239 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C240 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C241 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+
P
-AC 4
C243 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+
P
-AC 4
C244 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C245 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+P-AC 4
C246 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+
P
-AC 4
C247 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C248 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C249 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+P-AC 4
C250 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C252 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C253 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C254 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C255 10UF, CE, 16V, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ 4
C256 CC, 6.3V, 4.7U, 10%, 0603 150B-475K+P-AC 4
C257 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C258 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C259 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C260 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C261 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C262 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+
P
-AC 4
C263 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C264 220UF, CE, 6.3V, 20%, SM, 6.3X5.3, NOVER 157B-227M+3-LJU 4
C265 220UF, CE, 6.3V, 20%, SM, 6.3X5.3, NOVER 157B-227M+3-LJU 4
C266 220UF, CE, 6.3V, 20%, SM, 6.3X5.3, NOVER 157B-227M+3-LJU 4
C267 220UF, CE, 6.3V, 20%, SM, 6.3X5.3, NOVER 157B-227M+3-LJU 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
