Bose FreeSpace IZA 190-HZ Service Manual

53
Resistors (continued)
ELECTRICAL PART LIST
FreeSpace
®
ZA 190-HZ Main PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R345 402K, RMG, 1/16W, 1%, 0603 4723-4023+P 4
R346 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R347 210K, RMG, 1/16W, 1%, 0603 4723-214A+P 4
R348 22R, RMG, 1W, 5%, 2512 4728-220J+3 4
R349 24R, RMG, 1/4W, 1%, 1206 4725-240A+6 4
R350 24R, RMG, 1/4W, 1%, 1206 4725-240A+6 4
R351 49.9R, RMG, 1/4W, 1%, 1206 4725-49R9+6 4
R352 10R, RMG, 1/4W, 5%, 1206 4725-100J+6 4
R353 16R, RMG, 1/4W, 1%, 1206 4725-160A+6 4
R354 22R, RMOF, 5W, 5%, AT, MINI SIZE 471B-220J+2-
X
4
R355 49.9R, RMG, 1/4W, 1%, 1206 4725-49R9+6 4
R356 0R, RMG, 1/4W, 5%, (<50mOHM), 1206 4725-000J+6 4
R357 16R, RMG, 1/4W, 1%, 1206 4725-160A+6 4
R358 10R, RMG, 1/4W, 5%, 1206 4725-100J+6 4
R360 100K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-104A+P-R 4
R361 39K, RMG, 1/16W, 5%, 0603, HK,
RESISTOR/SAMSUNG
4723-393J+P-R 4
R362 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4
R363 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+P 4
R364 4.7K, RMG, 1/16W, 1%, 0603/1608. 4723-472A+P 4
R365 100K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-104A+P-R 4
R366 2.4K, RMG, 1/16W, 1%, 0603 4723-242A+P 4
R367 30K, RMG, 1/16W, 1%, 0603/1608 4723-303A+P 4
R368 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R369 39K, RMG, 1/10W, 1%, 0603 4720-393A+P 4
R370 39K, RMG, 1/10W, 1%, 0603 4720-393A+P 4
R371 22R, RMG, 1W, 5%, 2512 4728-220J+3 4
R374 47R, RMG, 1/16W, 5%, 0603, HK,
RESISTOR/SAMSUNG
4723-470J+P-R 4
R378 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R379 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R390 3.9K, RMG, 1/16W, 5%, 0603, HK,
RESISTOR/SAMSUNG
4723-392J+P-R 4
R391 39K, RMG, 1/16W, 5%, 0603, HK,
RESISTOR/SAMSUNG
4723-393J+P-R 4
R392 39K, RMG, 1/16W, 5%, 0603, HK,
RESISTOR/SAMSUNG
4723-393J+P-R 4
R393 22R, RMOF, 5W, 5%, AT, MINI SIZE 471B-220J+2-
X
4
R394 3.9K, RMG, 1/16W, 5%, 0603, HK,
RESISTOR/SAMSUNG
4723-392J+P-R 4
R395 3.9K, RMG, 1/16W, 5%, 0603, HK,
RESISTOR/SAMSUNG
4723-392J+P-R 4
R396 0R, RMG, 1/4W, 5%, (<50mOHM), 1206 4725-000J+6 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
