Bose FreeSpace IZA 190-HZ Service Manual

81
Capacitors (continued)
ELECTRICAL PART LIST
FreeSpace
®
IZA 250-LZ Rear Panel I/O PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C268 0.1UF, CC, 50V, 5%, 0603 150F-104J+
P
-AC 4
C271 0.1UF, CC, 50V, 5%, 0603 150F-104J+
P
-AC 4
C272 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C273 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C274 1000PF, CC, 50V, 5%, 0603, X7
R
150F-102J+
P
-AC 4
C275 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+P-AC 4
C276 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C277 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C278 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+
P
-AC 4
C279 0.1UF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C281 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C282 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C283 1000PF, CC, 50V, 5%, 0603, X7
R
150F-102J+
P
-AC 4
C284 0.1UF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C285 0.1UF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4

Inductors
Reference
Designator
Description
V
endor Part
Number
Note
L5 FERRITE, BEAD, SMD, ACB453215, 125 1802-0630+0 4
L200 FERRITE, BEAD, SMD, ACB453215, 125 1802-0630+0 4

Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D201 BAV99, SOT23, PHILIPS 4840-8970+3 4
D202 BAV99, SOT23, PHILIPS 4840-8970+3 4
D203 BAV99, SOT23, PHILIPS 4840-8970+3 4
D204 BAV99, SOT23, PHILIPS 4840-8970+3 4
D205 BAV99, SOT23, PHILIPS 4840-8970+3 4
D206 BAV99, SOT23, PHILIPS 4840-8970+3 4
D207 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY 480T-54S0+3 4
D208 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111S 480M-1110+3 4
D209 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111S 480M-1110+3 4
D210 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111S 480M-1110+3 4
D211 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111S 480M-1110+3 4
D212 SUPPRESSOR, 26V, 30A, ESD, TVM1G260M111S 480M-1110+3 4
D213 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM
(
RLZTE-116 4837-6V21+3 4
D214 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM(RLZTE-116 4837-6V21+3 4
D215 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM(RLZTE-116 4837-6V21+3 4


Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
