Bose FreeSpace IZA 250-LZ

28
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ Main PCB Assembly
Resistors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
R350 24R, RMG, 1/4W, 1%, 1206 4725-240A+6 4
R351 49.9R, RMG, 1/4W, 1%, 1206 4725-49R9+6 4
R352 10R, RMG, 1/4W, 5%, 1206 4725-100J+6 4
R353 16R, RMG, 1/4W, 1%, 1206 4725-160A+6 4
R354 22R, RMOF, 5W, 5%, AT, MINI, SIZE 471B-220J+2-
X
4
R355 49.9R, RMG, 1/4W, 1%, 1206 4725-49R9+6 4
R356 0R, RMG, 1/4W, 5%(<50 mOHM), 1206 4725-000J+6 4
R357 16R, RMG, 1/4W, 1%, 1206 4725-160A+6 4
R358 10R, RMG, 1/4W, 5%, 1206 4725-100J+6 4
R360 100K, RMG, 1/16W, 1%, 0603, HK, SAMSUNG 4723-104A+P-R 4
R361 39K, RMG, 1/16W, 5%, 0603, HK, SAMSUNG 4723-393J+P-R 4
R362 2K, RMG, 1/16W, 1%, 0603/1608 4723-202A+P 4
R363 20K, RMG, 1/16W, 1%, 0603/1608 4723-203A+
P
4
R364 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472A+P 4
R365 100K, RMG, 1/16W, 1%, 0603, HK, SAMSUNG 4723-104A+P-R 4
R366 2.4K, RMG, 1/16W, 1%, 0603 4723-242A+
P
4
R367 30K, RMG, 1/16W, 1%, 0603/1608 4723-303A+P 4
R368 100R, RMG, 1/16W, 1%, 0603 4723-101A+P 4
R369 39K, RMG, 1/10W, 1%, 0603 4720-393A+P 4
R370 39K, RMG, 1/10W, 1%, 0603 4720-393A+
P
4
R371 22R, RMG, 1W, 5%, 2512 4728-220J+3 4
R374 47R, RMG, 1/16W, 5%, 0603, HK, SAMSUNG 4723-470J+P-R 4
R378 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+
P
4
R379 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+
P
4
R390 3.9K, RMG, 1/16W, 5%, 0603, HK, SAMSUNG 4723-392J+P-R 4
R391 39K, RMG, 1/16W, 5%, 0603, HK, SAMSUNG 4723-393J+P-R 4
R392 39K, RMG, 1/16W, 5%, 0603, HK, SAMSUNG 4723-393J+P-
R
4
R393 22R, RMOF, 5W, 5%, AT, MINI, SIZE 471B-220J+2-X 4
R394 3.9K, RMG, 1/16W, 5%, 0603, HK, SAMSUNG 4723-392J+P-R 4
R395 3.9K, RMG, 1/16W, 5%, 0603, HK, SAMSUNG 4723-392J+P-R 4
R396 0R, RMG, 1/4W, 5%(<50 mOHM), 1206 4725-000J+6 4
R397 0R, RMG, 1/10W, 5%, 0805 4720-0R0J+J 4

Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
C300 3300PF, CC, 1000V, 10%, RLT, 10X4, X7
R
, 125C 150N-332K+K-SG 4
C301 470UF, CE, 250V, 20%, RL, 30X30, 105C 157R-477M+5-$$T 4
C302 470UF, CE, 250V, 20%, RL, 30X30, 105C 157R-477M+5-$$T 4
C303 3300PF, CC, 1000V, 10%, RLT, 10X4, X7R, 125C 150N-332K+K-SG 4
C304 330PF, CC, 1000V, 10%, RLT, Y5
P
, 5.5X3.5 150N-331K+K-JF 4
C305 47UF, CE, 10V, 20%, RLT, 5X11, 105C 157C-476M+K-IUT 4
C306 4.7UF, CE, 63V, 20%, RLT, 5X11, LOW, ESR, 105C 157I-475M+K-IURT 4
C308 0.015UF, CC, 630V, 10%, 1206, X7R 150M-153K+6-CF 4
C309 100UF, CE, 25V, 20%, RLT, 6.3X11, 105C, LOW,
ESR
157E-107M+K-
LURT
4

