44
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ Rear Panel I/O PCB Assembly
Capacitors (continued)
Reference
Designator
Description
endor Part
Number
Note
C268 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-
C 4
C271 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-
C 4
C272 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C273 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C274 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-
C 4
C275 0.01uF, CC, 50V, 10%, 0603, 1x2 150F-103K+P-AC 4
C276 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C277 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C278 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+
-
C 4
C279 0.1UF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C281 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C282 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C283 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-
C 4
C284 0.1UF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C285 0.1UF, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
Inductors
Reference
Designator
Description
endo
Part
Number
Note
L5 FERRITE, BEAD, SMD,
CB453215, 125 1802-0630+0 4
L200 FERRITE, BEAD, SMD,
CB453215, 125 1802-0630+0 4
Diodes
Reference
Designator
Description
endo
Part
Number
Note
D201 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3 4
D202 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3 4
D203 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3 4
D204 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3 4
D205 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3 4
D206 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3 4
D207 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY 480T-54S0+3 4
D208 DIODE, SUPPRESSOR, 26V, 30A, ESD,
TVM1G260M111, S
480M-1110+3 4
D209 DIODE, SUPPRESSOR, 26V, 30A, ESD,
TVM1G260M111, S
480M-1110+3 4
D210 DIODE, SUPPRESSOR, 26V, 30A, ESD,
TVM1G260M111, S
480M-1110+3 4
D211 DIODE, SUPPRESSOR, 26V, 30A, ESD,
TVM1G260M111, S
480M-1110+3 4
D212 DIODE, SUPPRESSOR, 26V, 30A, ESD,
TVM1G260M111, S
480M-1110+3 4
D213 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM 4837-6V21+3 4
D214 D
, 1/2W, 6.2VB, SMD, LL-34, ROHM 4837-6V21+3 4
D215 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM 4837-6V21+3 4
To Next Page
