Bose FreeSpace IZA 250-LZ

45
ELECTRICAL PART LIST
FreeSpace
®
IZA 190-HZ Rear Panel I/O PCB Assembly
Transistors
Reference
Designator
Description
V
endo
r
Part
Number
Note
Q200 TR, MMBT4403LT1G, SMD 4854-4030+3 4
Q201 TR, MMBT4403LT1G, SMD 4854-4030+3 4
Q202 TR, MMBT4403LT1G, SMD 4854-4030+3 4
Q203 TR, MMBT4403LT1G, SMD 4854-4030+3 4
Q204 TR, MMBT4403LT1G, SMD 4854-4030+3 4
Q205 TR, NPN, MMBT4401, SOT-23, HFE:, 20-300, SM 4854-4010+3 4
Q206 TR, MMBT4403LT1G, SMD 4854-4030+3 4
Q207 TR, MMBT4403LT1G, SMD 4854-4030+3 4
Q208 TR, MMBT4403LT1G, SMD 4854-4030+3 4
Q209 TR, NPN, MMBT4401, SOT-23, HFE:, 20-300, SM 4854-4010+3 4
Q210 TR, NPN, MMBT4401, SOT-23, HFE:, 20-300, SM 4854-4010+3 4

Integrated Circuits
Reference
Designator
Description
V
endo
r
Part
Number
Note
U214 IC, OP, AMP, SWITCH, NJM2120M, SOIC8 3132-3711+0 4
U216 IC, TL072CDR, DUAL, J-FET, INPUT, OP-AMP 3130-8020+0 4
U217 IC, TL072CDR, DUAL, J-FET, INPUT, OP-AMP 3130-8020+0 4
U218 IC, TL072CDR, DUAL, J-FET, INPUT, OP-AMP 3130-8020+0 4
U219 IC, OP, AMP, SWITCH, NJM2120M, SOIC8 3132-3711+0 4
U220 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890+0 4

Miscellaneous
Reference
Designator
Description
V
endo
r
Part
Number
Note
CH1 JACK, 2RC
A
, P15, H=10+9.5 2113-3153+0 4
CH2 JACK, 2RC
A
, P15, H=10+9.5 2113-3153+0 4
CH3 CONNECTOR, SOCKET, EURO, BLOCK, 4P, P5,
STRAIGHT, GREEN
2113-3148+0 4
J3 SOCKET, SPEAKER, 4P, P5, 250V, 12A, BLACK 2113-3148+1 4
LINE_OUT JACK, 2RCA, P15, H=10+9.5 2113-3153+0 4
MUTE SOCKET, M, 2P, P5, 300V, 15
A
, BLACK 2113-3361+1 4
S200 CONNECTO
R
, HEADE
R
, 4
P
, P2.54, S
T
, M 2101-3296+0 4
S201 CONNECTOR, HEADER, 4P, P2.54, ST, M 2101-3296+0 4
S214 SWITCH, DIP, SPST, 24V, 25MA, P2.54, 4PIN 5200-5019+0 4
SW204 SWITCH, SLIDE, 3P2T, 125V, 0.3A, VERT=6 5200-5015+0 3
VR201 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH, C 4751-226E+0 4
VR205 V
R
, ROTARY, 10K/10CX1, 20%, V, L=15, 18TEETH 4751-224E+0 4
VR206 VR, ROTARY, 100KAX2, 20%, V, L=15, 18TEET 4751-225E+0 4
VR207 VR, ROTARY, 100KAX2, 20%, V, L=15, 18TEETH 4751-225E+0 4

