Bose FreeSpace IZA 250-LZ

56
Capacitors (continued)
ELECTRICAL PART LIST
FreeSpace
®
ZA 190-HZ Main PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C380 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C381 1000P
F
, CC, 250V, 5%, 0805 150R-102J+J-BD 4
C382 1000UF, CE, 35V, 20%, RLT, 12.5X25, 105C, LOW
ESR
157Q-108M+K-
X&TR
4
C383 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C384 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C385 0.1U
F
, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C386 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C387 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C388 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C389 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C390 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C391 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C392 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C393 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C394 220PF, CC, 50V, 5%, 0603 150F-221J+P-AC 4
C395 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C396 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C397 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C398 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C399 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C400 0.1U
F
, CC, 100V, 10%, 1206, AVX 150H-104K+6-CFD 4
C401 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C402 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C404 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C406 0.1U
F
, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C407 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C408 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C409 1000P
F
, CC, 50V, 5%, 0603, X7
R
150F-102J+P-AC 4
C411 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C412 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C413 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C414 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C415 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C416 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C423 0.1UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C424 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C425 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C426 0.1uF, CC, 50V, 10%, 0805, 1.2X2.0 150F-104K+J-BD 4
C428 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C436 2200uF, CE, 10V, 20%, RL, 10x20 157C-228M+5-S9 4
C437 100uF, CE, 10V, 20%, R5, 5X11 157C-107M+K-IU 4
C449 330PF, CC, 250V, 10%, YKP, RL, 8.5X8.5 150R-331K+5-PP 4
C450 330PF, CC, 250V, 10%, YK
P
, RL, 8.5X8.5 150R-331K+5-PP 4
C485 470PF, CC, 50V, 5%, 0603 150F-471J+P-AC 4
C486 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C487 3300PF, CC, 1000V, 10%, RLT, 10X4, X7R, 125C 150N-332K+K-SG 4

