Bose FreeSpace IZA 250-LZ

57
Capacitors (continued)
ELECTRICAL PART LIST
FreeSpace
®
ZA 190-HZ Main PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C488 3300P
F
, CC, 1000V, 10%, RLT, 10X4, X7
R
, 125C 150N-332K+K-SG 4
CX300 0.33UF, CM, 300V, 10%, RB, P15, 18X15.5X10 1511-334K+9-03Z 4
CX301 0.33UF, CM, 300V, 10%, RB, P15, 18X15.5X10 1511-334K+9-03Z 4
XYC301 330PF, CC, 250V, 10%, YKP, RL, 8.5X8.5 150R-331K+5-PP 4
XYC303 330PF, CC, 250V, 10%, YK
P
, RL, 8.5X8.5 150R-331K+5-PP 4
XYC304 1000PF, CC, 400V, 20%, RL, Y5, , U, 9.5X8,
AH09E102MLO
150T-102M+5-RO 4
YC300 1000PF, CC, 400V, 20%, RL, Y5, , U, 9.5X8,
AH09E102MLO
150T-102M+5-RO 4

Inductors
Reference
Designator
Description
V
endor Part
Number
Note
L300 FERRITE, BEAD, INDUCTO
R
, BL01RN1A1F1J 1808-0680+0 4
L301 CHOKE-COMMON, MODE, 10MH, 10MH, MIN, AC,
240V, 2A, AL
1806-4037+0000 4
L302 CHOKE-COMMON, MODE, 10MH, 10MH, MIN, AC,
240V, 2A, AL
1806-4037+0000 4
L303 FERRITE, BEAD, INDUCTO
R
, BL01RN1A1F1J 1808-0680+0 4
L304 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L305 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L306 FERRITE, COIL, 22UH, 20%, BL19.2 1807-220M+9 4
L310 FERRITE, BEAD, INDUCTO
R
, BL01RN1A1F1J 1808-0680+0 4
L311 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L313 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L314 FERRITE, BEAD, INDUCTO
R
, BL01RN1A1F1J 1808-0680+0 4
L318 FERRITE, COIL, 22UH, 20%, BL19.2 1807-220M+9 4
L319 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L320 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L321 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L322 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L323 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L324 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4
L328 FERRITE, BEAD, SMD, ACB453215, 125, OHM 1802-0630+0 4

Diodes
Reference
Designator
Description
V
endor Part
Number
Note
B300 BRIDGE, 800V, 8
A
, GBU8K, RL 4840-9218+5 4
D300 FAST, 800V, 2
A
, HER207, AT 480R-2070+2 4
D303 ULTRA, 400V, 16A, MUR1640, TO-220AB, RB 4801-6400+9 4
D303A FERRITE, BEAD, 26430000101, (FAIR-RITE) 1808-0670+0 4
D304 ULTRA, 400V, 16
A
, MUR1640, TO-220AB, RB 4801-6400+9 4
D304C FERRITE, BEAD, 26430000101, (FAIR-RITE) 1808-0670+0 4
D305 200V, 0.2A, BAV21W, , , SOD-123, SMD, PANJIT 480V-21W0+3 4
D306 LL4148, SM 4804-1480+3 4
D307 RECTIFIE
R
, ES1D, 200V, 1.1
A
, SMD 4840-9190+3 4

