Bose FreeSpace IZA 250-LZ

61
Resistors (continued)
ELECTRICAL PART LIST
FreeSpace
®
ZA 190-HZ Rear I/O Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R532 100R, RMG, 1/16W, 1%, 0603 4723-101A+
P
4
R558 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R559 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R560 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R561 39K, RMG, 1/16W, 5%, 0603, HK,
RESISTOR/SAMSUNG
4723-393J+P-R 4
R562 0R, RMG, 1/16W, 1%, 0603 4723-000A+
P
4
R563 0R, RMG, 1/10W, 1%, 0805 4720-000A+J 4
R564 0R, RMG, 1/10W, 1%, 0805 4720-000A+J 4
R565 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A+P 4
R566 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A+
P
4
R567 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-R 4
R568 4.7K, RMG, 1/16W, 1%, 0603/1608. 4723-472A+P 4
R569 4.7K, RMG, 1/16W, 1%, 0603/1608. 4723-472A+P 4
R570 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-
R
4
R571 10K, RMG, 1/16W, 1%, 0603, HK,
RESISTOR/SAMSUNG
4723-103A+P-
R
4

Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
C501 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C502 10UF, CE, 50V, 20%, RLT, 4X7 157F-106M+K-GM 4
C503 10UF, CE, 50V, 20%, RLT, 4X7 157F-106M+K-GM 4
C504 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C505 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C506 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C507 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C508 0.01UF, CC, 50V, 5%, 0603 150F-103J+P-AC 4
C509 0.01UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C511 0.01UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C514 1000PF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C515 10UF, CE, 50V, 20%, RLT, 4X7 157F-106M+K-GM 4
C519 0.01UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C521 0.01UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C526 22UF, CE, 16V, 20%, RLT, 4X7 157D-226M+K-GM 4
C527 22UF, CE, 16V, 20%, RLT, 4X7 157D-226M+K-GM 4
C528 0.01UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C529 0.01UF, CC, 50V, 5%, 0603 150F-104J+P-AC 4
C531 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C532 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C542 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C543 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4
C544 100PF, CC, 50V, 5%, 0603/1608, 1X2 150F-101J+P-AC 4

