Bose FreeSpace IZA 250-LZ

87
ELECTRICAL PART LIST
Capacitors
FreeSpace
®
IZA 250-LZ MIC PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C115 10UF CE 16V 20% SM 3X5.4 85C-2000H 157D-106MEJ 4
C116 10UF CE 16V 20% SM 3X5.4 85C-2000H 157D-106MEJ 4
C120 0.1uF CC 50V 10% 0603/1608 1x2 150F-104KAC 4
C121 0.1uF CC 50V 10% 0603/1608 1x2 150F-104KAC 4
C122 220UF CE 6.3V 20% SM 6.3X5.3 NOVER 157B-227MLJU 4
C123 220UF CE 6.3V 20% SM 6.3X5.3 NOVER 157B-227MLJU 4
C125 220UF CE 6.3V 20% SM 6.3X5.3 NOVER 157B-227MLJU 4
C127 220UF CE 6.3V 20% SM 6.3X5.3 NOVER 157B-227MLJU 4
C128 0.1uF CC 50V 10% 0603/1608 1x2 150F-104KAC 4
C130 100PF CC 50V 5% 0603/1608 1X2 150F-101JAC 4
C131 470PF CC 50V 5% 0603 150F-471JAC 4
C132 470PF CC 50V 5% 0603 150F-471JAC 4
C134 100PF CC 50V 5% 0603/1608 1X2 150F-101JAC 4
C136 0.1uF CC 50V 10% 0603/1608 1x2 150F-104KAC 4
C138 1000PF CC 50V 5% 0603 X7R 150F-102JAC 4
C145 0.1uF CC 50V 10% 0603/1608 1x2 150F-104KAC 4
C146 0.1uF CC 50V 10% 0603/1608 1x2 150F-104KAC 4
C150 100PF CC 50V 5% 0603/1608 1X2 150F-101JAC 4
C151 100PF CC 50V 5% 0603/1608 1X2 150F-101JAC 4
C160 0.1uF CC 50V 10% 0603/1608 1x2 150F-104KAC 4
C161 0.1uF CC 50V 10% 0603/1608 1x2 150F-104KAC 4
C162 10UF CE 16V 20% SM 3X5.4 85C-2000H 157D-106MEJ 4
C163 10UF CE 16V 20% SM 3X5.4 85C-2000H 157D-106MEJ 4

Inductors
Reference
Designator
Description
V
endor Part
Number
Note
FB101 FERRITE CHIP 0603 BLM18AG102SN1D 1808-0878 4
FB102 FERRITE CHIP 0603 BLM18AG102SN1D 1808-0878 4
FB103 FERRITE CHIP 0603 BLM18AG102SN1D 1808-0878 4
FB104 FERRITE CHIP 0603 BLM18AG102SN1D 1808-0878 4
FB105 FERRITE CHIP 0603 BLM18AG102SN1D 1808-0878 4
FB106 FERRITE CHIP 0603 BLM18AG102SN1D 1808-0878 4
FB107 FERRITE CHIP 0603 BLM18AG102SN1D 1808-0878 4
FB108 FERRITE CHIP 0603 BLM18AG102SN1D 1808-0878 4

Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D101 BAV99 SOT23 PHILIPS 4840-8970 4
D104 BAV99 SOT23 PHILIPS 4840-8970 4
Z142 DIODE SUPPRESSOR 26V 30A ESD
TVM1G260M111 S
480M-1110 4
Z143 DIODE SUPPRESSOR 26V 30A ESD
TVM1G260M111 S
480M-1110 4

