Bose FreeSpace IZA 250-LZ

88
ELECTRICAL PART LIST
Transistors
FreeSpace
®
IZA 250-LZ MIC PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
Q100 NPN MMBT4401 SOT-23 HFE: 20-300 SM 4854-4010 4
Q101 NPN MMBT4401 SOT-23 HFE: 20-300 SM 4854-4010 4
Q102 MMBT4403LT1G SMD 4854-4030 4
Q103 MMBT4403LT1G SMD 4854-4030 4
Q104 MMBT4403LT1G SMD 4854-4030 4
Q105 MMBT4403LT1G SMD 4854-4030 4
Q106 MMBT4403LT1G SMD 4854-4030 4
Q107 MMBT4403LT1G SMD 4854-4030 4
Q108 MMBT4403LT1G SMD 4854-4030 4
Q109 MMBT4403LT1G SMD 4854-4030 4

Integrated Circuits
Reference
Designator
Description
V
endor Part
Number
Note
U101 TL072CDR DUAL J-FET INPUT OP-
A
MP 3130-8020 4
U102 NJM2068M-#ZZZB DUAL OP AM
P
3130-6890 4

Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
J1 CONNECTOR 9P 2MM 2102-090S 4
J100 JACK MIC PHONE COMBO 11P NCJ10FI-H-0 NE 2113-3213 4
CON GND WIRE GROUND 1P L=58 GREEN/YRL RING 7012-9970 3,4

