Bose GS SERIES III 3.2.1 - Connecting Module to Media Center

10
SETUP
ItalianoSvenska DeutschNederlands EnglishFrançais Español
1. Notice the arrow on the top of the multi-pin plug at
each end of the Acoustimass module cable.
2. Make sure you can see the arrow on top before you
insert either end of the cable.
3
Connecting
the module to
the media center
What you need to use:
Acoustimass
®
module cable
Media center
Acoustimass module
Arrow
