21
SETUP
Italiano SvenskaDeutsch NederlandsEnglish FrançaisEspañol
5. Plug the other end of your digital cable into
the appropriate AUDIO IN connector on the
media center.
The example here shows an Optical digital
connection only.
To use video pass through
This calls for another composite cable or two S-Video
cables, which are available at most electronics stores.
You can make a pass through connection if:
• You have a Composite or S-Video connection
between the TV and the media center (not HDMI or
Component).
AND:
• You want to connect another video component
through the media center to the TV.
Be sure to use one matched pair as shown here:
DO NOT use either of the two ONLY PASS-THROUGH
connectors (on the left) if you have made an HDMI or
Component connection VIDEO OUT TO TV.
Continue with on the next page.
