Bose L1 Compact User Manual

17
CARE AND MAINTENANCE
Technical Information
Mechanical
Electrical
• AC power rating
100-240V 50/60Hz 200W max
• Peak inrush current
230V: 18.2 Amps
120V: 9.7 Amps
Part Dimensions Weight
L1
®
Compact Power Stand with
Loudspeaker Array
16½" H x 13¼" W x 16¾" D
(41.8 cm x 33.9 cm x 42.6 cm)
24.6 lbs. (11.2 kg)
L1
®
Compact Loudspeaker Array 16" H x 2¾" W x 2¾" D
(40.8 cm x 7 cm x 7.1 cm)
3.0 lbs. (1.35 kg)
L1
®
Compact Extensions (2) 32½" H x 2¾" W x 2¾" D
(83 cm x 7 cm x 7.1 cm)
2.3 lbs. (1.05 kg) each
Collapsed position
(assembled)
16½" H x 13¼" W x 16¾" D
(41.8 cm x 33.9 cm x 42.6 cm)
24.6 lbs. (11.2 kg)
Extended position
(assembled)
78½" H x 13¼" W x 16¾" D
(199.5 cm x 33.9 cm x 42.6 cm)
29.2 lbs. (13.3 kg)
Shipping Cartons Weight
L1
®
Compact loudspeakers 30.4 lbs. (13.8 kg)
L1
®
Compact extensions 7.5 lbs. (3.4 kg)
BOSE, L1, and TONEMATCH are registered trademarks of Bose Corporation in the U.S. and other countries.
Cajun_Care+Maint.fm Page 17 Tuesday, December 23, 2008 1:24 PM

Bose L1 Compact Specifications

General

Product color	Black
Recommended usage	Universal
Multi-Room Streaming (MRS) support	-
Number of drivers	6
Speaker placement	Stand-mountable
Audio output channels	- channels
RMS rated power	- W
AirPlay	No
Microphone in	Yes
Connectivity technology	Wired
Power source type	AC

Weight and Dimensions

Depth	425.45 mm
Width	336.55 mm
Height	1993.9 mm
Weight	13240 g
