Bose L1 Pro16 Service Manual

14
Main Part List
L1 Pro16 I/O Panel Assy (see Figure 3)
Item
Number
Description
Material
Number
Vendor Part
Number
Qty/Note
29 SCREW, T3xL10 - T15330101F611
30 HEATSINK CHIPSET POWER - T130203600200
31 GEL 30 - T980200001430
32 THERMAL PAD 3 - T181700001680
33 POWER-AMP BOARD 863628-001S T910000074770
34 THERMAL PAD_CONDUCTIVE
SILICONE_H50 K
- T181700001730
35 HEATSINK STANDBY IC - T130211300100
36 HEATSINK AMP CHIPSET POWER - T130203500110
37 HEATSINK CHIPSET POWER BACK - T130203700300
38 SCREW, M3XL9 - T15130091C610
39 SHIELD COVER - T130208000100
40 SCREW (FOR SHIELD COVER) - T153300612631
41 SCREW M3XL14 0.5P BLUE
ZINC+HT K
- T15130141F611
42 SPONGE_YU356A
FOAM_ADHSIVE 3212 K
- T180500032730
43 GASKET FOR SHIELD COVER 3 - T180500030690
44 SCREW, T3xL20 - T15330201F610
45 SILICONE GLUE SLD-8854 - T980200000210
46 HEATSINK RECTIFIER BRIDGE
POWER PCBA
- T130203800100
47 U CLIP - T180200016470
48 SCREW, T3xL12 - T15330122F610
49 THERMAL PAD POWER CHIPSET - T181700001700
50 EVA FOAM_38
DEGREE_BLACK_ADHSIVE DS11
- T180500032670
51 SMPS CONNECT CABLE P3.96
3PIN VH-3Y88 K
- T641700170300
52 GASKET_IO PANEL_ENCLOSURE-L 857362-0010 T180500031380
53 GASKET_IO PANEL_ENCLO-
SURE-R
857362-0020 T180500031370
54 GASKET FOR PANEL 843001-0110 T180500031130
55 FIRE BOX - T100402700100
56 GASKET FOR PCB CONNECTOR1 - T180500031140
57 ASSY, PCBA, MAIN-IO, PROG,
SVCE
865429-001S T910000074740
58 GLUE K-704NB - T980200000680

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
