Bose L1 Pro16 Service Manual

15
Main Part List
L1 Pro16 I/O Panel Assy (see Figure 3)
Item
Number
Description
Material
Number
Vendor Part
Number
Qty/Note
59 EVA_38 DEGREE_BLACK_ADHSIVE
DS11 L24XW22XT0.5 K
- T180500032740
60 EVA 38°+PET L32.6XW28.1XT0.5MM
K
- T180500032680
61 POWER LIGHT GUIDE - T100402400100
62 NUT, M4 - T181000001240
63 EQ LIGHT GUIDE - T100402200100
64 1P YELLOW\GREEN 16AWG
UL1015 100MM X-P K
- T641700184000
65 GASKET FOR FIRE BOX 1 - T180500031090
66 TUBE PVC 30 - T690200008700
67 BUTTON SELECTION 1 - T100403500100
68 POWER BUTTON - T100401900100
69 HOT MELT GLUE XH150 - T980200000440
70 PE FOAM_BLACK_ADHSIVE
DS11 OD19XID13XT1.0 K
- T180500032770
71 POWER BUTTON RING - T100402100100
72 NUT M3 - T181000000520
73 PLUG 250VA 10A NA JINJIA K - T691200007600 3
74 IO PANEL - T130202500100
NA GAP FILLER, THERMAL, ONE PART,
55CC
749859-0020 -

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
